Dell E2010H User Manual

Plug and Play Capability
You can install the monitor in any Plug and Play-
compatible system. The monitor automatically provides the computer with its Extended Display Identification Data (EDID) using Display Data Channel
(DDC) protocols so that the system can configure itself and optimize the monitor settings. Most monitor installations are automatic. You can select different settings if required.
1
TMDS RX2-
2
TMDS RX2+
3
TMDS Ground
4
Floating
5
Floating
6
DDC Clock
7
DDC Data
8
Floating
9
TMDS RX1-
10
TMDS RX1+
11
TMDS Ground
12
Floating
13
Floating
14
+5V/+3.3V power
15
Selftest
16
Hot Plug Detect
17
TMDS RX0-
18
TMDS RX0+
19
TMDS Ground
20
Floating
21
Floating
22
TMDS Ground
23
TMDS Clock+
24
TMDS Clock-
Flat Panel Specifications
*Dell E2010H/E2210H/E2310H Flat Panel monitor color gamut (typical) is based on CIE 1976 (83%) and CIE1931 (72%) test standards.
Model number
Dell E2010H Flat Panel Monitor
Dell E2210H Flat Panel Monitor
Dell E2310H Flat Panel Monitor
Screen type
Active matrix - TFT LCD
Active matrix - TFT LCD
Active matrix - TFT LCD
Panel Type
TN
TN
TN
Screen dimensions
20.0 inches
(20.0-inch wide viewable image size)
21.5 inches
(21.5-inch wide viewable image size)
23 inches
(23-inch wide viewable image size)
Preset display area:
l Horizontal
l Vertical

442.8 mm (17.4 inches)
249.0 mm (9.8 inches)

476.6 mm (18.8 inches)
268.1 mm (10.6 inches)

509.8 mm (20.1 inches)
286.7 mm (11.3 inches)
Pixel pitch
0.277 mm
0.248 mm
0.266 mm
Viewing angle:
l Horizontal
l Vertical

170°typical
160°typical

170°typical
160°typical

170°typical
160°typical
Luminance output
250 CD/m² (typical)
250 CD/m² (typical)
250 CD/m²(typical)
Contrast ratio
1000 to 1 (typical)
1000 to 1 (typical)
1000 to 1 (typical)
Faceplate coating
Anti-glare
Anti-glare
Anti-glare
Backlight
2 CCFL edgelight system
2 CCFL edgelight system
2 CCFL edgelight system
Response Time
5ms typical
5ms typical
5ms typical
Color Gamut
72% (typical)
72% (typical)
72% (typical)
Downloaded from ManualMonitor.com Manuals

Dell E2010H Specifications

General

3D	Yes
HD type	-
Panel type	TN
Pixel pitch	0.277 x 0.277 mm
Aspect ratio	16:9
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Display technology	LED
Viewable size, vertical	249 mm
Viewing angle, vertical	160 °
Display number of colors	16.78 million colors
Viewable size, horizontal	442.8 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1600 x 900
DVI-I ports quantity	0
Product color	Black
Market positioning	Business
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Panel mounting interface	100 x 100 mm
Input current	1.6 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	26 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Package weight	6350 g

Weight and Dimensions

Depth (with stand)	151.9 mm
Width (with stand)	481.2 mm
Height (with stand)	363.2 mm
Weight (with stand)	4850 g
Weight (without stand)	3500 g
