toorganizeallcablesasshownabove.
Attaching the Soundbar(optional)
To attach the Soundbar:
Removing the Stand
To remove the stand:
1. Rotate the stand to allow access to the stand release button.
2. Press and hold the stand release button.
3. Lift the stand up and away from the monitor.
Wall Mounting (Optional)
CAUTION: DonotusewithanydeviceotherthanDellSoundbar.
1.
Working from the back of the monitor, attach Soundbar by aligning the two slots with the two tabs along the bottom of the monitor.
2.
Slide the Soundbar to the left until it snaps into place.
3.
Connect the Soundbar with the power brick.
4.
Plug the power cable of the brick to a nearby power outlet.
5.
Insert the lime-green mini stereo plug from the rear of the Soundbar into the computer's audio output jack.
NOTE: To prevent scratches on the LCD screen while removing the stand,ensure that the monitor is placed on a clean surface.

Dell E2210 Specifications

General

3D	-
Panel type	TN
Pixel pitch	0.282 x 0.282 mm
Aspect ratio	16:10
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Display technology	LED
Viewing angle, vertical	160 °
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1680 x 1050 (WSXGA+)
DVI-I ports quantity	0
Input current	1.6 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	31 W
Power consumption (standby)	1 W
Power consumption (typical)	28 W
Product color	Black
Market positioning	Business
Weight (imperial)	9.7 lbs
Package weight (imperial)	15.5 lbs
LED indicators	Stand-by
Package weight	7030 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %
Cables included	AC, DVI, VGA
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	163.9 mm
Width (with stand)	511.2 mm
Height (with stand)	406.7 mm
Depth (without stand)	- mm
Weight (without stand)	4400 g
