Electrical Specifications
Video input signals
Analog RGB, 0.7 Volts +/- 5%, positive polarity at 75 ohm input impedance
Digital DVI-D TMDS, 600mV for each differential line, positive polarity at 50 ohm input
impedance
Synchronization input signals
Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG
(Composite SYNC on green)
AC input
voltage/frequency/current
100 to 240 VAC/50 or 60 Hz + 3 Hz/1.6A (Max.)
Inrush current
120 V: 30 A (Max.)/240 V: 60 A (Max.) (E1910)
120V:40A (Max.)/ 240V:80A (Max.) (E2210)
Physical Characteristics
Model
Dell E1910 Flat Panel Monitor
Dell E2210 Flat Panel Monitor
Connector type
15-pin D-subminiature, blue
connector; DVI-D, white
connector
15-pin D-subminiature, blue
connector; DVI-D, white
connector
Signal cable type
Digital: Detachable, DVI-D, Solid
pins, shipped detached from
the monitor
Analog: Detachable, D-Sub,
15pins, shipped attached to
the monitor
Digital: Detachable, DVI-D, Solid
pins, shipped detached from
the monitor
Analog: Detachable, D-Sub,
15pins, shipped attached to
the monitor
Dimensions (with stand)
Height (Extended)
14.32 inches (363.74 mm)
16.01 inches (406.7 mm)
Width
17.45 inches (442.85 mm)
20.13 inches (511.2 mm)
Depth
5.78 inches (146.86 mm)
6.44inches(163.9mm)
Dimensions (without stand)
Height
11.41 inches (289.75 mm)
13.15 inches (334.0 mm)
Width
17.43 inches (442.85 mm)
20.13 inches (511.2 mm)
Depth
2.32 inches (59.00 mm)
2.54 inches (64.5 mm)
Stand dimensions
Height (Extended)
11.39 inches (289.25 mm)
12.39 inches (314.7 mm)
Width
9.88 inches (250.86 mm)
10.47 inches (265.9 mm)
Depth
5.78 inches (146.86 mm)
6.44 inches (163.7 mm)
Weight
Weight with packaging
12.70 lbs (5.76 kg)
15.50 lbs (7.03 kg)
Weight with stand assembly and cables
11.11 lbs (5.04 kg)
13.27 lbs (6.02 kg)
Weight without stand assembly
(For wall mount or VESA mount
considerations - no cables)
7.91 lbs (3.59 kg)
9.70 lbs (4.40 kg)
Weight of stand assembly
2.20 lbs (1.00 kg)
2.58 lbs (1.17 kg)

Dell E2210 Specifications

General

3D	-
Panel type	TN
Pixel pitch	0.282 x 0.282 mm
Aspect ratio	16:10
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Display technology	LED
Viewing angle, vertical	160 °
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1680 x 1050 (WSXGA+)
DVI-I ports quantity	0
Input current	1.6 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	31 W
Power consumption (standby)	1 W
Power consumption (typical)	28 W
Product color	Black
Market positioning	Business
Weight (imperial)	9.7 lbs
Package weight (imperial)	15.5 lbs
LED indicators	Stand-by
Package weight	7030 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %
Cables included	AC, DVI, VGA
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	163.9 mm
Width (with stand)	511.2 mm
Height (with stand)	406.7 mm
Depth (without stand)	- mm
Weight (without stand)	4400 g
