Table 23. Expansion card riser specifications
Supported VxRail
configurations
Riser configuration and
supported risers
Slot
description
PCIe slots (Height
and length)
Processor
connection
VxRail E560, E560F, and E560N
appliance
Riser configuration 2
(1A+2A)
Three x16 slots
Slot 1: x16 low profile,
half length
Processor 1
Slot 2: x16 low profile,
half length
Processor 1
Slot 3: x16 low profile,
half length
Processor 2
Riser configuration 4 (1A) Two x16 slots
Slot 2: x16 low profile,
half length
Processor 1
Memory specifications
Table 24. Memory specifications
DIMM
type
DIMM rank
DIMM
capacity
Single processor Dual processors
Minimum RAM Maximum RAM Minimum RAM Maximum RAM
LRDIMM Quad rank 64 GB 384 GB 768 GB 768 GB 1536 GB
LRDIMM Quad rank 128 GB 512 GB 1.5 TB 1 TB 3 TB
RDIMM Dual rank 16 GB 96 GB 192 GB 192 GB 384 GB
RDIMM Dual rank 32 GB 192 GB 384 GB 384 GB 768 GB
Storage controller specifications
The VxRail E560, E560F, and E560N appliance supports:
● Internal storage controller cards: HBA330 and Boot Optimized Server Storage (BOSS-S1).
Hard drive specifications
The VxRail E560, E560F, and E560N appliance supports NVMe, SAS, SATA, Nearline SAS hard drives or SSDs.
Table 25. Supported drive options
Ten drive appliances Up to ten 2.5 inch, hot swappable NVMe, SAS, SAS/SATA SSD, or Nearline
SAS hard drives.
Ports and connectors specifications
The VxRail E560, E560F, and E560N appliance supports USB ports, NIC ports, VGA ports, serial connector, and an IDSDM card
that supports two internal dual SD module.
USB ports
The following table provides more information about the USB specifications:
Technical specifications
23
