Hardware Overview 5
Hardware Overview
This section contains information about device characteristics and modular
hardware configurations for the S4820T switch.
The S4820T has the following physical dimensions:
•
434 x 460 x 43.5 mm (W x D x H).
•
17.09 x 18.11 x 1.71 inches (W x D x H).
The S4820T has a chassis design with 640Gbps switching bandwidth as listed
below:
•
S4820T = 48 port 10GBase-T + 4 port 40G QSFP+
The system also provides one RS-232 interface RJ-45 YOST console port and
a dedicated Ethernet service port for out-of-band (OOB) management
functions.
The S4820T has the following features:
•
Supports one universal serial bus (USB) port
•
Forty-eight 10Gbps ports
•
Four fixed 40Gbps QSFP ports for a 40Gbps transceiver
•
On-board high-performance central processing unit (CPU) system with
large memory, P2020/128 MB NOR Flash/2GB DDR III RAM.
•
Temperature monitoring (TMP75)
•
Software-readable thermal monitor
•
Real time clock (RTC) support
•
Hot-plugging redundant power supply
•
Current monitoring for Power management
•
Removable fan that you can manage
• Standard 1U chassis high
