Dell I15N-2727BK User Manual

32 Palm-Rest Assembly
9 Remove the power button board. See "Removing the Power Button Board"
on page 35.
Replacing the Palm-Rest Assembly
1 Follow the instructions in "Before You Begin" on page 9.
2 Replace the power button board. See "Replacing the Power Button Board"
on page 36.
3 Align the palm-rest assembly on the computer base and gently snap the
palm-rest assembly into place.
4 Slide the touch-pad cable and power-button board cable into the
connectors on the system board and press down on the connector latches
to secure them.
5 Replace the two screws on the palm-rest assembly.
6 Replace the keyboard. See "Replacing the Keyboard" on page 17.
1 palm-rest assembly 2 plastic scribe
1
2
