58 Display
Replacing the Display Assembly
1
Follow the instructions in "Before You Begin" on page 9.
2
Place the display assembly in position and replace the four screws (two on
each side) that secure the display assembly to the computer base.
3
Route the display cable and Mini-Card antenna cables through the routing
guides.
4
Connect the Mini-Card antenna cables to the Mini-Card. See "Replacing
the Mini-Card" on page 27.
5
Connect the display cable to the connector on the system board.
6
Replace the hinge cover. See "Replacing the Hinge Cover" on page 53.
7
Follow the instructions from step 3 to step 7 in "Replacing the Palm-Rest
Assembly" on page 32.
1 display assembly 2 screws (4)
