86 Adding and Replacing Parts
www.dell.com | support.dell.com
2 Align the Mini PCI card with the connector at a 45-degree angle, and press the Mini PCI
card into the connector until it clicks.
3 Connect the antenna cables to the Mini PCI card.
4 Replace the cover.
CD or DVD Drive
1
Complete the instructions in "Before You Begin" on page 77.
2
Turn the computer over, loosen the captive screw in the memory module cover, and lift the
cover away from the computer.
Mini PCI card
Mini PCI card connector
antenna cables (2)
