Replacing the I/O board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at dell.com/regulatory_compliance.
Procedure
1 Slide the I/O board under the tab on the computer base and align the
screw hole on the I/O board with the screw hole on the computer base.
2 Replace the screw that secures the I/O board to the computer base.
3 Slide the I/O-board cable into the I/O board and press down on the latch
to secure the cable.
Post-requisites
1 Follow the procedure from step 4 to step 11 in “Replacing the palm rest”.
2 Replace the keyboard.
3 Follow the procedure from step 4 to step 6 in “Replacing the hard drive”.
4 Replace the base cover.
5 Replace the battery.
51
