Replacing the display assembly
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at dell.com/regulatory_compliance.
Procedure
1 Align the screw holes on the display hinges with the screw holes on the
computer base.
2 Replace the screws that secure the display hinges to the computer base.
3 Route the display cable through the routing guides on the computer
base.
4 Route the antenna cables through the routing guides on the computer
base and slide the antenna cables through the slot on the computer base.
5 Slide the I/O-board cable into the I/O board and press down on the latch
to secure the cable.
Post-requisites
1 Follow the procedure from step 4 to step 8 in “Replacing the system
board”.
2 Follow the procedure from step 4 to step 11 in “Replacing the palm rest”.
3 Replace the keyboard.
4 Replace the wireless card.
5 Replace the memory modules.
6 Follow the procedure from step 4 to step 6 in “Replacing the hard drive”.
7 Replace the base cover.
8 Replace the battery.
71
