Removing the Wireless Card | 33
Removing the Wireless Card
WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before Working Inside Your
Computer" on page 9. After working inside your computer, follow the instructions
in "After Working Inside Your Computer" on page 11. For additional safety best
practices information, see the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.
Prerequisites
1 Remove the battery. See "Removing the Battery" on page 12.
2 Remove the base cover. See "Removing the Base Cover" on page 20.
3 Remove the keyboard. See "Removing the Keyboard" on page 17.
4 Remove the palm rest. See "Removing the Palm Rest" on page 29.
Procedure
1 Disconnect the antenna cables from the wireless card.
2 Remove the screw that secures the wireless card to the system board.
1 screw 2 antenna cables (2)
3 wireless card
book.book Page 33 Wednesday, October 2, 2013 3:11 PM
