Back to Contents Page
Display
Dell™Inspiron™9300ServiceManual
Display Assembly
Display Bezel
Display Panel
Display Latch
Display Assembly
Removing the Display Assembly
1. Follow the instructions in "Before Working Inside Your Computer."
2. Turn the computer over and loosen the two captive screws on the Mini PCI card cover.
3. Disconnect the antenna cables from the Mini PCI card, if applicable.
CAUTION: Before you begin the following procedure, see the safety instructions in the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as the back panel) on the computer.
NOTICE: To avoid damaging the system board, you must remove the main battery before you begin working inside the computer.
NOTE: If a Mini PCI card is installed, you will need to disconnect the antenna cables from the card. If one is not installed, detach the antenna cables
from their secured location.
