Integrated Graphics Controller
Integrated Graphics
Controller
Intel HD 5500 (Intel Broadwell Celeron/i3/i5/i7 Processors)
Model
Dell Latitude 14 & 15 3000 Series Models: 3450/3550
Bus Type
Internal PCIe
Memory Interface
DDR3L 1333/1600
Clock Speeds
Core i7 5500U: 2.4GHz
Core i5 5300U: 2.3GHz
Core i5 5200U: 2.2GHz
Core i3 5005U: 2.0GHz
Celeron 3205U: 1.5GHz
Max Graphics dynamic
frequency
Core i7 5500U: 300/950 MHz
Core i5 5300U: 300/900 MHz
Core i5 5200U: 300/900 MHz
Core i3 5005U: 300/850 MHz
Celeron 3205U: 100/800 MHz
Graphics Level
i3/i5/i7 : Intel HD 5500 GT2
Celeron 3205U : Intel® HD Graphics
Estimated Maximum Power Consumption
(TDP)
15W
Display
Support
eDP (internal), HDMI, VGA
Maximum Color Depth
32bit
Maximum Vertical Refresh Rate
Up to 85Hz depending on resolution
Operating Systems Graphics/ Video API Support
DirectX* 11.1, DirectX* 11.1+, OpenGL* 4.0, OpenGL* 4.2 support
Supported Resolutions and Max Refresh Rates (Hz)
(Note: Analog and/or digital)
Max Digital: (HDMI): 4096x2304 @ 24 Hz
Analog: (VGA): 1920x1200/32bpp @ 60Hz
Numbers of Displays Supported
3 displays (LCD + HDMI + VGA) in triple-clone or extended desktop
37

Dell Latitude 3000 Series Specifications

General

Series	Latitude 3000 Series
Category	Laptop
Operating System	Windows 10 Pro
Processor	Intel Celeron, Intel Pentium, Intel Core i3, Intel Core i5, Intel Core i7
Storage	HDD, SSD
Display	13.3-inch to 15.6-inch HD or FHD (depending on the specific model)
Graphics	Intel UHD Graphics
Battery	3-cell or 4-cell lithium-ion
Ports	USB, HDMI, Ethernet, SD card reader, headphone/microphone combo jack
Wireless	Bluetooth
Weight	Varies by configuration (typically between 3 lbs to 5 lbs)
