Dell Latitude 3000 Series User Manual

Dell Latitude 3000 Series Battery Specification
3-cell (43 WHr)* 4-cell (58WHr)
Battery Type
Lithium ion (Prismatic cell ) Lithium ion (Prismatic cell )
Dimension
( outline ID 3cell same as 4cell ) ( outline ID 3cell same as 4cell )
Length
208.25mm 208.25mm
Width
124.7 mm 124.7 mm
Height
7.8mm 7.8mm
Weight
3cell:283g
4cell :350g
Voltage
3cell : 11.1VDC 4cell :7.4 VDC
Typical Amp
-hour capacity
3.9Ahr 7.8Ahr
Typical Watt
-hour capacity
43Whr 58Whr
Temperature
Operating
Charge: 0 °C to 50 °C,
32 °F to 122 °F
Discharge: 0 °C to 70 °C,
32 °F to 158 °F
Charge: 0 °C to 50 °C,
32 °F to 122 °F
Discharge: 0 °C to 70 °C,
32 °F to 158 °F
Non-Operating
-20 °C to 65 °C
-4 °F to 149 °F
-20 °C to 65 °C
-4 °F to 149 °F
Charging time
0~15degC: 4 hour
16~45degC: 2 hours
46~60degC: 3 hours
0~15degC: 4 hour
16~45degC: 2 hours
46~60degC: 3 hours
ExpressCharge
Capable
Yes Yes
BATTMAN Capable
Yes Yes
Express charge benefits
• For a battery advertised as having the ExpressCharge™ feature, the battery typically will have greater than 80% charge after
about an hour of charging with the system off, and fully charged in about 2 hours with the system off.
• Enabling Expresscharge™ requires that both the Latitude notebook and the battery that is used on the system be
ExpressCharge™ capable. If any of the above requirements is missing, ExpressCharge™ will not be enabled.
45
*
option available beginning January 2015

Dell Latitude 3000 Series Specifications

General

Series	Latitude 3000 Series
Category	Laptop
Operating System	Windows 10 Pro
Processor	Intel Celeron, Intel Pentium, Intel Core i3, Intel Core i5, Intel Core i7
Storage	HDD, SSD
Display	13.3-inch to 15.6-inch HD or FHD (depending on the specific model)
Graphics	Intel UHD Graphics
Battery	3-cell or 4-cell lithium-ion
Ports	USB, HDMI, Ethernet, SD card reader, headphone/microphone combo jack
Wireless	Bluetooth
Weight	Varies by configuration (typically between 3 lbs to 5 lbs)
