49
Dell Latitude 3000 Series
Keyboards Hot Key Definition
Fn
Key Combination
Function
Fn+ESC
Fn
Toggle
Fn+ F1
Speaker Mute
Fn + F2
Volume Down
Fn + F3
Volume Up
Fn + F4
Previous
Fn + F5
Play/Pause
Fn + F6
Next
Fn + F8
Display Toggle (Win + P)
Fn + F9
Search
Fn + F10
Increase Keyboard Backlight Brightness
Fn + F11
Panel Brightness Down
Fn + F12
Panel Brightness Up
Fn + Prt Scr
Wireless On/Off
Fn + Left Cursor
Home (3450 only)
Fn + Right Cursor
End (3450 only)
Fn Key Mode:
Standard = The F1-F12 keys behave as function keys. Holding <Fn> is required to access their secondary functions.
Secondary~14~= The F1-F12 keys control the secondary functions. <Fn> is required to access the standard functions.
