Page #38 background image
Graphics
Controller
Discrete Graphics: NVIDIA GeForce 830M
Models
3450/3550
Graphics Memory
2GB
DDR3 Graphics Memory
Bus Type
Internal
PCIe
Memory Interface
64
-Bit
Clock Speeds
1059MHz Core / 900MHz Memory
Estimated Maximum Power Consumption
20W
Display
Support
None.
3450/3550 uses Hybrid Graphics, Intel graphics drives all
physical
outputs
Maximum Color Depth
N/A
Maximum Vertical Refresh Rate
N/A
Operating Systems Graphics/ Video API Support
DirectX 11.1, OpenGL 4.2
Supported Resolutions and Max Refresh Rates (Hz
)
(
Note: Analog and/or digital)
N/A
Numbers of Displays Supported*
Please
refer to the “Display Options” Section
Nvidia Discrete Graphics Controller
38
* All display outputs are driven by the Intel graphics solution. Discrete graphics does not directly drive
any display outputs
