Hardware Overview
This section contains information about device characteristics and modular
hardware configurations for the S6000 switch.
The S6000 has the following physical dimensions:
• 434 x 460 x 43.5 mm (W x D x H).
• 17.09 x 18.11 x 1.71 inches (W x D x H).
The S6000 has a chassis design with 1280Gbps switching bandwidth as listed
below:
• 32 port 40G QSFP+
• Up to 96 10G ports with QSFP+ breakout
The system also provides one RS-232 interface RJ-45 YOST console port and a
dedicated Ethernet management port for out-of-band (OOB) management
functions.
The S6000 has the following features:
• Supports one universal serial bus (USB-A) port
• Supports one USB-B console port
• Thirty-two 40Gbps QSFP ports for 40Gbps transceivers
• On-board high-performance central processing unit (CPU) system with large
memory
• Temperature monitoring
• Software-readable thermal monitor
• Real time clock (RTC) support
• Hot-plugging redundant power supply
• Current monitoring for power management
• Three removable fan modules
• Standard 1U chassis high
