26 | Setting Up the Monitor
Attaching the Cable Cover
NOTE: The cable cover is detached when the monitor is shipped from the factory.
1 Insert the two tabs on the bottom part of the cable cover in the slots on the
back of the monitor.
2 Press the cable cover till it snaps into place.
Removing the Monitor Stand
CAUTION: To prevent scratches on the LCD screen while removing the
stand,îmake sure that the monitor is placed on a soft, clean surface.
NOTE: The procedure below is applicable for the default stand. If you
purchased any other stand, see the documentation shipped with the stand to
set it up.
To remove the stand:
1 Place the monitor on a soft cloth or cushion.
2 Press and hold the stand-release button.
3 Lift the stand up and away from the monitor.
