Dell P2423D User Manual

Setting up the monitor │ 37
VESA wall mounting (optional)
Q40G024N-700-XXA
DELL P2423D
Flat Panel Monitor /Monitor Plano Panel /Moniteur écran plat /液晶顯示器
Model No. /Modelo /N°de modelo /型號/모델명/モデル番号: P2423Dc
정격입력/Entrada de energía:100-240V 50/60Hz,1.5A
輸入電源:交流電壓100-240伏特,1.5安培,50/60赫茲
Удельная мощность рабочего режима - XXXX Вт/см² Consumo de energía en operación: XXX Wh
Потребляемая мощность изделием в режиме ожидания - 0,XX Вт
Потребляемая мощность изделием в выключенном режиме - 0,XX Вт
The equipment must be connected to an earthed mains socket-outlet.
L'appareil doit être branché sur une prise de courant munie d'une mise à la terre.
Made in China /Fabricado en China/сделанный в Китай /Fabriqué en Chine/中國製造 警語: 使用過度恐傷害視力。
www.dell.com/regulatory_compliance Raheen Business Park Limerick Ireland (for EU Only)
CAN ICES-003(B)/NMB-003(B) For UK only: Cain Road, Bracknell, RG12 1LF
(1) this device may not cause harmful interference, and
XXXXX
R33037
RoHS
XXXXXX-XX
IS 13252 (Part 1)/
IEC 60950-1
R-41082465
www.bis.gov.in
XXXXXX-XXXX
R-R-E2K-P2423Dc
신청인:DELL INC.
제조자:L&T Display Technology(Fujian)Ltd.(for Korea)
080-200-3800
デル・テクノロジーズ
入力:100V, 1.5 A, 50/60 Hz
XXXXXXXX
Q40G024N-700-XXA
DELL P2423D
Flat Panel Monitor /Monitor Plano Panel /Moniteur écran plat /液晶顯示器
Model No. /Modelo /N°de modelo /型號/모델명/モデル番号: P2423Dc
정격입력/Entrada de energía:100-240V 50/60Hz,1.5A
輸入電源:交流電壓100-240伏特,1.5安培,50/60赫茲
Удельная мощность рабочего режима - XXXX Вт/см² Consumo de energía en operación: XXX Wh
Потребляемая мощность изделием в режиме ожидания - 0,XX Вт
Потребляемая мощность изделием в выключенном режиме - 0,XX Вт
The equipment must be connected to an earthed mains socket-outlet.
L'appareil doit être branché sur une prise de courant munie d'une mise à la terre.
Made in China /Fabricado en China/сделанный в Китай /Fabriqué en Chine/中國製造 警語: 使用過度恐傷害視力。
www.dell.com/regulatory_compliance Raheen Business Park Limerick Ireland (for EU Only)
CAN ICES-003(B)/NMB-003(B) For UK only: Cain Road, Bracknell, RG12 1LF
(1) this device may not cause harmful interference, and
XXXXX
R33037
RoHS
XXXXXX-XX
IS 13252 (Part 1)/
IEC 60950-1
R-41082465
www.bis.gov.in
XXXXXX-XXXX
R-R-E2K-P2423Dc
신청인:DELL INC.
제조자:L&T Display Technology(Fujian)Ltd.(for Korea)
080-200-3800
デル・テクノロジーズ
入力:100V, 1.5 A, 50/60 Hz
XXXXXXXX
SVC Tag:
1234567
Express Service
Code:
123 456 789 0
S/N: CN-0723H6-
TV200-1C1-001L
-A00
Date of Mfg/生产日期/生產日期: December. 2021
Q40G024N-700-XXA
液晶显示器
型号:P2423D
输入电源:
100-240V 50/60Hz,1.5A
中国制造
DELL P2423D
(Screw dimension: M4 x 10 mm).
See the documentation that shipped with the VESA-compatible wall mounting kit.
1. Place the display on a soft cloth or cushion at the edge of the desk.
2. Remove the stand. See Removing the monitor stand.
3. Remove the four screws that secure the display back cover.
4. Install the mounting bracket from the wall mounting kit to the display.
5. To mount the monitor on the wall, see the documentation that shipped with the
wall mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall mount bracket
with minimum weight/load bearing capacity of 13.76 kg ( P2423D) /
18.16 kg (P2723D).

Dell P2423D Specifications

General

Input current	1.5 A
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	55 W
Power consumption (standby)	0.3 W
Power consumption (typical)	16 W
Color gamut	99 %
Pixel pitch	0.2058 x 0.2058 mm
Screen shape	Flat
Pixel density	123 ppi
Backlight type	LED
Display diagonal	23.8 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	49 - 75 Hz
Maximum refresh rate	60 Hz
Response time (fast)	8 ms
Horizontal scan range	29 - 113 kHz
Supported video modes	480p, 576p, 720p, 1080i, 1080p, 1440p
Viewable size diagonal	604.5 mm
Viewable size, vertical	296.35 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	526.85 mm
Display brightness (typical)	300 cd/m²
Pivot angle	90 - 90 °
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
HDMI version	1.4
DisplayPort version	1.2
USB upstream port type	USB Type-B
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Package weight	7440 g
Sustainability certificates	ENERGY STAR, RoHS, TCO
Feet color	Silver
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, DisplayPort, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	5.42 mm
Bezel width (side)	5.48 mm
Depth (with stand)	179.57 mm
Width (with stand)	537.8 mm
Height (with stand)	496.11 mm
Weight (with stand)	5070 g
Bezel width (bottom)	16.72 mm
Depth (without stand)	52.15 mm
Height (without stand)	318.5 mm
Weight (without stand)	3440 g
