About your monitor 9
Product features
The Dell P2423D/P2723D monitor has an active matrix, Thin-Film Transistor (TFT),
Liquid Crystal Display (LCD), and LED backlight. The monitor features include:
P2423D: 60.45 cm (23.8 in.) viewable area display (measured diagonally).
P2723D: 68.47 cm (27 in.) viewable area display (measured diagonally).
2560 x 1440 resolution, with full-screen support for lower resolutions.
Color gamut of 99% sRGB (typical).
Digital connectivity with DisplayPort and HDMI.
Equipped with 1 USB-B upstream port and 4 SuperSpeed USB 5 Gbps (USB 3.2
Gen1) Type-A downstream ports.
Plug and play capability if supported by your computer.
On-Screen Display (OSD) adjustments for ease of setup and screen optimization.
Power and joystick buttons lock.
Removable stand and Video Electronics Standards Association (VESA™) 100 mm
mounting holes for flexible mounting solutions.
Tilt, swivel, height, and rotate adjustment capabilities.
Security lock slot.
Stand lock.
≤0.3 W standby power when in Standby Mode.
Supports Dell Display Manager.
Optimize eye comfort with a flicker-free screen and low blue light feature.
The monitor use Low Blue Light panel and compliance with TUV Rheinland
(Hardware Solution) at factory reset/default setting model (Preset mode:
Standard).
WARNING: The possible long-term effects of blue light emission
from the monitor may cause damage to the eyes, which includes but
is not limited to eye fatigue and digital eye strain. ComfortView Plus
feature is designed to reduce the amount of blue light emitted from the
monitor to optimize eye comfort.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell P2423D and is the answer not in the manual?

Dell P2423D Specifications

General IconGeneral
Input current1.5 A
AC input voltage100 - 240 V
Power supply typeInternal
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (max)55 W
Power consumption (standby)0.3 W
Power consumption (typical)16 W
Color gamut99 %
Pixel pitch0.2058 x 0.2058 mm
Screen shapeFlat
Pixel density123 ppi
Backlight typeLED
Display diagonal23.8 \
Anti-glare screenYes
Display technologyLCD
Native aspect ratio16:9
Vertical scan range49 - 75 Hz
Maximum refresh rate60 Hz
Response time (fast)8 ms
Horizontal scan range29 - 113 kHz
Supported video modes480p, 576p, 720p, 1080i, 1080p, 1440p
Viewable size diagonal604.5 mm
Viewable size, vertical296.35 mm
Contrast ratio (typical)1000:1
Display number of colors16.7 million colors
Viewable size, horizontal526.85 mm
Display brightness (typical)300 cd/m²
Pivot angle90 - 90 °
Tilt angle range-5 - 21 °
Panel mounting interface100 x 100 mm
HDMI version1.4
DisplayPort version1.2
USB upstream port typeUSB Type-B
VGA (D-Sub) ports quantity0
USB Type-A downstream ports quantity4
Package weight7440 g
Sustainability certificatesENERGY STAR, RoHS, TCO
Feet colorSilver
Product colorBlack
Heavy metals freeHg (mercury)
Market positioningBusiness
Operating altitude0 - 5000 m
Non-operating altitude5000 - 12192 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 80 %
Cables includedAC, DisplayPort, USB
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Bezel width (top)5.42 mm
Bezel width (side)5.48 mm
Depth (with stand)179.57 mm
Width (with stand)537.8 mm
Height (with stand)496.11 mm
Weight (with stand)5070 g
Bezel width (bottom)16.72 mm
Depth (without stand)52.15 mm
Height (without stand)318.5 mm
Weight (without stand)3440 g
