Dell P2423D User Manual

Regulatory information │ 73
Regulatory information
FCC notices (U.S. Only) and other regulatory information
For FCC notices and other regulatory information, see the regulatory compliance
website located at www.dell.com/regulatory_compliance.
EU product database for energy label and product information
sheet
P2423D: https://eprel.ec.europa.eu/qr/1057427
P2723D: https://eprel.ec.europa.eu/qr/1057546
Contacting Dell
To contact Dell for sales, technical support, or customer service issues, see www.
dell.com/contactdell
NOTE: Availability varies by country and product, and some services
may not be available in your country.
NOTE: If you do not have an active Internet connection, you can find
contact information on your purchase invoice, packing slip, bill, or Dell
product catalog.

Dell P2423D Specifications

General

Input current	1.5 A
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	55 W
Power consumption (standby)	0.3 W
Power consumption (typical)	16 W
Color gamut	99 %
Pixel pitch	0.2058 x 0.2058 mm
Screen shape	Flat
Pixel density	123 ppi
Backlight type	LED
Display diagonal	23.8 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	49 - 75 Hz
Maximum refresh rate	60 Hz
Response time (fast)	8 ms
Horizontal scan range	29 - 113 kHz
Supported video modes	480p, 576p, 720p, 1080i, 1080p, 1440p
Viewable size diagonal	604.5 mm
Viewable size, vertical	296.35 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	526.85 mm
Display brightness (typical)	300 cd/m²
Pivot angle	90 - 90 °
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
HDMI version	1.4
DisplayPort version	1.2
USB upstream port type	USB Type-B
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Package weight	7440 g
Sustainability certificates	ENERGY STAR, RoHS, TCO
Feet color	Silver
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, DisplayPort, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	5.42 mm
Bezel width (side)	5.48 mm
Depth (with stand)	179.57 mm
Width (with stand)	537.8 mm
Height (with stand)	496.11 mm
Weight (with stand)	5070 g
Bezel width (bottom)	16.72 mm
Depth (without stand)	52.15 mm
Height (without stand)	318.5 mm
Weight (without stand)	3440 g
