Dell P53F User Manual

Installing the base cover
1 Slide the base cover to align with the screw holes on the computer.
2 Replace the M2.5X5.0 screws to secure the base cover to the computer.
3 Install the:
a battery
b battery cover
4 Follow the procedure in After working inside your computer.
Memory module
Removing the primary memory module
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a battery cover
b battery
c base cover
3 To remove primary memory module:
a Pry the retention clips away from the memory module until it pops up.
b Lift the memory module and remove it from the computer.
Removing and installing components
13
