Replacing the battery-status
light cable
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
NOTE: The battery-status light cable is an assembly that includes LED
indicators and a digital-array microphone.
Procedure
1 Using the alignment posts, place the battery-status light cable on the palm-rest
assembly.
2 Route the battery-status light cable through the routing guides and adhere it to
the palm-rest assembly.
3 Adhere the tape that secures the battery-status light cable to the palm-rest
assembly.
4 Slide the battery-status light cable into the battery-status light cable connector
and close the latch to secure the cable.
5 Adhere the tape that secures the battery-status light cable to the keyboard-
controls board.
Post-requisites
1 Replace the battery.
2 Replace the base cover.
