Troubleshooting Your System 111
9 Reconnect and power on each USB device one at a time.
10 If a device causes the same problem, power down the device, replace the
USB cable, and power up the device.
If the problem persists, replace the device.
If all troubleshooting fails, see "Getting Help" on page 133.
Troubleshooting a Serial I/O Device
1 Turn off the system and any peripheral devices connected to the
serial port.
2 Swap the serial interface cable with another working cable, and turn on the
system and the serial device.
If the problem is resolved, replace the interface cable.
3 Turn off the system and the serial device, and swap the device with a
comparable device.
4 Turn on the system and the serial device.
If the problem is resolved, replace the serial device.
If the problem persists, see "Getting Help" on page 133.
Troubleshooting a NIC
1 Run the appropriate online diagnostic test. See "Running the System
Diagnostics" on page 125.
2 Restart the system and check for any system messages pertaining to the
NIC controller.
3 Check the appropriate indicator on the NIC connector. See "NIC Indicator
Codes" on page 18.
• If the link indicator does not light, check all cable connections.
• If the activity indicator does not light, the network driver files might
be damaged or missing.
Remove and reinstall the drivers if applicable. See the NIC's
documentation.
• Change the autonegotiation setting, if possible.
book.book Page 111 Wednesday, August 12, 2009 4:51 PM

Dell PowerEdge R210 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	C2
FSB Parity	No
Processor cache	4 MB
Processor cores	2
Processor model	i3-530
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-500 Desktop Series
Processor socket	LGA 1156 (Socket H)
Processor threads	4
Processor codename	Clarkdale
Execute Disable Bit	Yes
Motherboard chipset	Intel® 3420
Processing Die size	81 mm²
Processor frequency	2.93 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
Graphics & IMC lithography	45 nm
PCI Express configurations	1x16, 2x8
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	73 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	22
Physical Address Extension (PAE)	36 bit
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3 1066/1333
Number of Processing Die Transistors	382 M
Memory channels supported by processor	Dual
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	16 GB
HDD size	3.5 \
RAID support	-
Optical drive type	DVD-RW
Total storage capacity	250 GB
Maximum storage capacity	2 TB
Memory slots	4x DIMM
Internal memory	2 GB
Memory clock speed	1333 MHz
Buffered memory type	Unregistered (unbuffered)
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	2 x 1 GB
Maximum graphics card memory	8 MB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	733 MHz
I/O ports	1x PCIe x16 G2
Graphics card	G200eW
Dimensions (WxDxH)	431 x 393.7 x 42.6 mm
Non-operating relative humidity (non-condensing)	5 - 95 %
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version	2.0
Power supply	250 W
Power requirements	100 - 240 V
Compatible operating systems	Windows SQL Server 2008 R2/Small Business Server 2008/Essential Business Server 2008/Foundation R2/Server 2008 SP2/Server 2008 R2, Novell, Linux.
Chassis type	Rack (1U)
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Processor ARK ID	46472

Weight and Dimensions

Depth	393.7 mm
Width	431 mm
Height	42.6 mm
