Dell PowerEdge R510 Technical Guide

Dell
PowerEdge R510 Technical Guide 18
4 Mechanical
4.1 Chassis Description
PowerEdge R510 chassis is a 2U rack system. The chassis is not swappable. Supported configurations are
detailed in Table 3.
Table 3. Supported Chassis Configurations
4-HDD Configuration
8-HDD Configuration
12-HDD Configuration
5 x cabled 3.5‖ HDD bay
Non-Redundant 480W PSU
Quad pack diagnostic LED
8 x hot-swap 3.5‖ or 2.5‖ HDD bay
750W redundant PSU (n+0 or n+1
option)
11G diagnostic LCD (identical to the
PowerEdge R710)
12 x hot-swap 3.5‖ or 2.5‖ HDD
bay + 2 x internal cabled 2.5‖ HDD
750W redundant PSU (available for
n+0 or n+1 option)
Rack-ear diagnostic LED
Redundant system cooling
4.2 Dimensions and Weight
Table 4. PowerEdge R510 Weight
4-HDD Configuration
8-HDD Configuration
12-HDD Configuration
Form Factor
2U Rack
Dimension
(HxWxD)
3.40 x 17.19 x 24.09 (in);
86.4 x 436.6 x 610.2 (mm)
3.42 x 17.53 x 26.17 (in);
86.7 x 445.2 x 664.6 (mm)
Max Weight
16 Kg/35.2 lbs
22.5 Kg/49.5 lbs
29.0Kg/63.8lbs
Empty Weight
13.6 Kg/29.92 lbs
13.5 Kg/29.7 lbs
15.85 Kg/34.87 lbs
Table 5. PowerEdge R510 Dimensions
Note:
Measurements in this table correspond to the diagram shown in Figure 3.
PowerEdge
R510
Configuration
Xa
Xb
Y
Za w/ bezel
Za w/o bezel
Zb*
Zc
4 and 8 HDD
482.4 mm
436.6 mm
86.4 mm
35.0 mm
21.0 mm
610.2
mm
642.0
mm
12 HDD
482.4 mm
445.2 mm
86.76 mm
35.0 mm
21.0 mm
664.65
mm
697.05
mm
* Zb goes to the nominal rear wall external surface where the motherboard I/O connectors reside.

Dell PowerEdge R510 Specifications

General

HDD size	3.5 \
Hot-swap	Yes
HDD capacity	450 GB
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	900 GB
Number of HDDs installed	2
Number of HDDs supported	8
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	64 GB
Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF6
Processor cache	8 MB
Processor cores	4
Processor model	E5540
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Processing Die size	263 mm²
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	80 W
CPU multiplier (bus/core ratio)	19
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
PS/2 ports quantity	0
Serial ports quantity	1
USB 2.0 ports quantity	6
Display	LCD
L1 cache	0.064 MB
Form factor	-
Graphics card	G200eW
Dimensions (WxDxH)	86.4 x 436.6 x 609.6 mm
Compatible operating systems	Microsoft Windows Small Business Server 2008/2003/ Novell SUSE Linux Enterprise Server 11/10 SP2 Linux Red Hat Enterprise 5.3/4.7 VMware vSphere Version 4.0 VMware ESX v3.5 / ESXi v3.5
Power consumption (typical)	1100 W
Noise level	42 dB
Chassis type	Rack (2U)
PCI Express x4 slots	3
Processor ARK ID	37104
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Weight	13500 g
