Dell PowerEdge R510 Technical Guide

Dell
PowerEdge R510 Technical Guide 69
Remote Access Controller) is responsible for acting as an interface between the host system and its
management software and the periphery devices. These periphery devices consist of the PSUs, the storage
backplane, integrated SAS HBA or PERC 6/I, and control panel with display.
The optional upgrade to iDRAC6 provides features for managing the server remotely or in data center lights-
out environments.
Advanced iDRAC features require the installation of the optional iDRAC6 Enterprise card.
15.4 Lifecycle Controller and Unified Server Configurator
Embedded management is comprised of several interdependent pieces:
• Lifecycle Controller
• Unified Server Configurator
• iDRAC6
• vFlash
Lifecycle controller powers the embedded management features. It is integrated and tamperproof storage
for system-management tools and enablement utilities (firmware, drivers, etc.).
Dell Unified Server Configurator (USC) is a local 1:1 graphical user interface embedded on Lifecycle
Controller that aids in local server provisioning in a pre-OS environment. For servers with iDRAC Express, the
Lifecycle Controller offers OS install, platform updates, platform configuration, and diagnostics capabilities.
For servers without iDRAC6 Express, this utility has limited functionality and offers OS install and diagnostics
capabilities only.
To access the Unified Server Configurator, press the <F10> key within 10 seconds of the Dell logo’s
appearance during the system boot process. Current functionality enabled by the Unified Server
Configurator is detailed in the following table.
Table 30. Unified Server Configurator Features and Description
Feature
Description
Faster O/S Installation
Drivers and the installation utility are embedded on
system, so no need to scour DELL.COM
Faster System Updates
Integration with Dell support automatically directed
to latest versions of the Unified Server Configurator,
iDRAC, RAID, BIOS, NIC, and Power Supply
Update Rollback
Ability to recover to previous known good state for all
updatable components
More Comprehensive Diagnostics
Diagnostic utilities are embedded on system
Simplified Hardware Configuration
Detects RAID controller and allows user to configure
virtual disk and choose virtual disk as boot device,
eliminating the need to launch a separate utility. Also
provides configuration for iDRAC, BIOS, and NIC/LOM.
15.5 iDRAC6 Express
The optional iDRAC6 Express is the first tier of iDRAC6 upgrades. In addition to upgrading the system with a
Lifecycle Controller, the iDRAC6 Express offers the following key features:
• Graphical web interface
• Standard-based interfaces

Dell PowerEdge R510 Specifications

General

HDD size	3.5 \
Hot-swap	Yes
HDD capacity	450 GB
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	900 GB
Number of HDDs installed	2
Number of HDDs supported	8
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	64 GB
Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF6
Processor cache	8 MB
Processor cores	4
Processor model	E5540
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Processing Die size	263 mm²
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	80 W
CPU multiplier (bus/core ratio)	19
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
PS/2 ports quantity	0
Serial ports quantity	1
USB 2.0 ports quantity	6
Display	LCD
L1 cache	0.064 MB
Form factor	-
Graphics card	G200eW
Dimensions (WxDxH)	86.4 x 436.6 x 609.6 mm
Compatible operating systems	Microsoft Windows Small Business Server 2008/2003/ Novell SUSE Linux Enterprise Server 11/10 SP2 Linux Red Hat Enterprise 5.3/4.7 VMware vSphere Version 4.0 VMware ESX v3.5 / ESXi v3.5
Power consumption (typical)	1100 W
Noise level	42 dB
Chassis type	Rack (2U)
PCI Express x4 slots	3
Processor ARK ID	37104
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Weight	13500 g
