Using the System Setup Program and UEFI Boot Manager 81
For more information about setting up USC, configuring hardware and
firmware, and deploying the operating system, see the Dell Unified Server
Configurator User’s Guide on the Dell Support website at
support.dell.com/manuals.
Baseboard Management Controller Configuration
NOTE: If an iDRAC6 Express card is installed on the system, the Baseboard
Management Controller (BMC) utility is replaced by the iDRAC 6 utility.
The BMC enables configuring, monitoring, and recovery of systems remotely.
BMC provides the following features:
• Uses the system’s integrated NIC
• Enables fault logging and SNMP alerting
• Provides access to system event log and sensor status
• Allows control of system functions including power on and off
• Functions independently of the system’s power state or the system’s
operating system
• Provides text console redirection for system setup, text-based utilities, and
operating system consoles
NOTE: To remotely access the BMC through the integrated NIC, you must connect
the network connection to integrated NIC1.
For additional information on using BMC, see the documentation for the
BMC and systems management applications.
Entering the BMC Setup Module
1 Turn on or restart your system.
2 Press < Ctrl><E > when prompted after POST.
If your operating system begins to load before you press <
Ctrl><E >,
allow the system to finish booting, and then restart your system and try
again.
book.book Page 81 Tuesday, June 9, 2009 4:09 PM

Dell PowerEdge T410 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBV4
Processor cache	12 MB
Processor cores	4
Processor model	E5620
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Motherboard chipset	Intel® 5500
Number of QPI links	2
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	3.5 \
Optical drive type	DVD-RW
Total storage capacity	250 GB
Maximum storage capacity	12 TB
Number of HDDs supported	6
Memory slots	8x DIMM
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Maximum graphics card memory	8 MB
Graphics card	G200eW
Dimensions (W x D x H) (imperial)	8.58 x 24.28 x 17.52 \
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of power supply units	-
Compatible operating systems	Microsoft SQL Server 2008 R2/Windows Small Business Server 2008/Essential Business Server 2008/Server 2008 SP2, x86/x64/Server 2008 R2/HPC Server 2008; Novell SUSE Linux Enterprise Server; Red Hat Enterprise Linux.
Chassis type	Tower
Processor ARK ID	47925
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	616.8 mm
Width	217.9 mm
Height	444.9 mm
