Dell PowerEdge T710 User Manual

168 Troubleshooting Your System
12 Place the system upright and on its feet on a flat and stable surface,
reconnect the system to the electrical outlet, and turn on the system and
attached peripherals.
13 Enter the System Setup program and check the system memory setting.
See "Memory Settings Screen" on page 61.
If the problem is not resolved, proceed with the next step.
14 Turn off the system and attached peripherals, and disconnect the system
from the power source.
15 Open the system. See "Opening the System" on page 85.
16 Remove the cooling shroud. See "Removing the Cooling Shroud" on
page 87.
17 If a diagnostic test or error message indicates a specific memory module as
faulty, swap or replace the module.
18 To troubleshoot an unspecified faulty memory module, replace the
memory module in the first DIMM socket with a module of the same type
and capacity. See "Installing Memory Modules" on page 104.
19 Replace the cooling shroud. See "Removing the Cooling Shroud" on
page 87.
20 Close the system. See "Closing the System" on page 86.
21 Place the system upright and on its feet on a flat and stable surface,
reconnect the system to the electrical outlet, and turn on the system and
attached peripherals.
22 As the system boots, observe any error message that appears and the
diagnostic indicators on the front of the system.
23 If the memory problem is still indicated, repeat step 14 through step 22 for
each memory module installed.
If the problem persists after all memory modules have been checked,
see
"Getting Help
" on page 193 .
book.book Page 168 Monday, June 15, 2009 11:33 AM

Dell PowerEdge T710 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF8
Processor cache	4 MB
Processor cores	4
Processor model	E5506
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5520
Number of QPI links	2
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD speed	15000 RPM
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD-ROM
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs supported	6
Graphics card	G200
Graphics card family	Matrox
Memory slots	18x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	192 GB
Memory layout (slots x size)	2 x 2 GB
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	8
PCI Express x8 slots	5
Power supply	1100 W
Number of power supply units	-
Compatible operating systems	Windows Small Business Server 2011 Windows Small Business Server 2008 Windows Server 2008 SP2, x86/x64 (x64 includes Hyper-V) Windows Server 2008 R2 SP1, x64 (includes Hyper-V v2) Windows HPC Server 2008 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Chassis type	Tower (5U)
Processor ARK ID	37096

Weight and Dimensions

Depth	731.8 mm
Width	217.9 mm
Height	466.3 mm
Weight	35300 g
