Table 4. SFP56-DD port LEDs
LED Description
Link/Activity LED—200GbE, 100GbE, 40GbE, or 10GbE mode
● Off—No link/activity
● Solid green—Port link is up
● Flashing green ~30ms—Port activity operating
● Solid yellow—Use CLI to check LED status
● Flashing yellow, one second on; one second off—Port
beacon
Table 5. SFP+ port LEDs
LED Description
Link LED
● Off—No link
● Solid green—Link operating at maximum speed, 10G
● Flashing green—Port activity at maximum speed
● Solid yellow—Link operating at a lower speed,1G
● Flashing yellow, one second on; one second off—port
beacon
Activity LED
● Off—No link
● Flashing green—port activity
Prerequisites
The following is a list of components that are required for successful switch installation:
NOTE: For detailed installation instructions, see Site preparations and S5448F-ON switch installation.
● S5448F-ON switch or multiple switches, if stacking
● AC or DC country- and regional-specific cables to connect the AC or DC power source to each of the switch AC or DC
power supplies
● Rail mounting brackets for rack installation, included
● Screws for rack installation, not included
● #1 and #2 Phillips screw drivers, not included
● Torx screwdriver, not included
● Ground cable screws for L-bracket, included
● Copper/fiber cables
Other optional components are:
● Ground cable and lug for the frame-end of the ground cable
● Extra mounting brackets
● Extra power supply unit
●
Extra fan module
NOTE: The DC ground lug kit ships with the other accessories inside the shipping box.
S5448F-ON switch configurations
You can order the S5448F-ON switch in several different configurations.
● S5448F-ON AC or DC Normal Airflow switch—one U, 48 x 100 GbE SFP56-DD ports, eight x 400 GbE QSFP56-DD ports,
two 10 GbE SFP+ ports, two power supplies, and six fan subsystems
● S5448F-ON AC or DC Reverse Airflow switch—one U, 48 x 100 GbE QSFP56-DD ports, eight x 400 GbE QSFP56-DD ports,
two 10 GbE SFP+ ports, two power supplies, and six fan subsystems
● Fan with airflow from the I/O side to the PSU side—Normal
● Fan with airflow from the PSU side to the I/O side—Reverse
● AC or DC power supply with airflow from the I/O side to the PSU side—Normal
The S5448F-ON switch
11
