Dell UltraSharp 38 User Manual

22  │  About your monitor
Pin assignments
DisplayPort connector
Pin number 20-pin side of the connected signal cable
1 ML3 (n)
2 GND
3 ML3 (p)
4 ML2 (n)
5 GND
6 ML2 (p)
7 ML1 (n)
8 GND
9 ML1 (p)
10 ML0 (n)
11 GND
12 ML0 (p)
13 GND
14 GND
15 AUX (p)
16 GND
17 AUX (n)
18 Hot Plug Detect
19 Re-PWR
20 +3.3 V DP_PWR
Non-operating 12192 m (40000 ft) (maximum)
Thermal dissipation • 835.97 BTU/hour (maximum)
• 118.74 BTU/hour (typical)

Dell UltraSharp 38 Specifications

General

Screen Size	37.5 inches
Resolution	3840 x 1600
Panel Type	IPS
Aspect Ratio	21:9
Refresh Rate	60 Hz
Brightness	300 cd/m²
Contrast Ratio	1000:1
Color Support	1.07 billion colors
Connectivity	USB-C, HDMI, DisplayPort
VESA Mount	100 x 100 mm
Response Time	5 ms (gray to gray)
Ports	HDMI, DisplayPort, USB-C, USB 3.0
Speakers	2x 9W
Viewing Angle	178° (H) / 178° (V)
Color Gamut	99% sRGB
Adjustability	Height, tilt, swivel
