18 | About Your Monitor

Universal Serial Bus (USB) Interface

This section gives you information about the USB ports that are available on the monitor.

NOTE: This monitor is Super-Speed USB 3.0 compatible.

* Up to 2A on USB downstream port (port with lightning icon) with BC1.2

compliance devices or normal USB devices.

USB Upstream Connector

Transfer Speed Data Rate Power Consumption*

Super-speed 5 Gbps 4.5 W (Max, each port)

High speed 480 Mbps 4.5 W (Max, each port)

Full speed 12 Mbps 4.5 W (Max, each port)

Pin Number 9-pin Side of the Connector

1 VCC

2 D-

3 D+

4 GND

5 SSTX-

6 SSTX+

7 GND

8 SSRX-

9 SSRX+
