About Your Monitor | 7

Bottom View

* Headphone usage is not supported for the audio line out connector.

Bottom view without monitor stand

Label Description Use

1 AC power cord

connector

Connect the power cable.

2 Dell Soundbar

mounting slots

Attach the optional Dell Soundbar. (Concealed below

removable plastic sheets)

3 DP in connector Connect your computer with DP cable.

4 Mini DisplayPort in

connector

Connect your computer with Mini-DP to DP cable.

5 DisplayPort out (MST)

connector

DisplayPort output for MST (Multi-Stream Transport)

capable monitor. DP 1.1 monitor can only be

connected as the last monitor in the MST chain. To

enable MST, refer to instruction on section

Connecting the monitor for DP Multi-Stream Transport

(MST) function

6 HDMI (MHL) port

connector

Connect your MHL devices with MHL cable.

7 Audio-Line out Connect your speakers*.

8 USB upstream port Connect the USB cable that came with your monitor

to the computer. Once this cable is connected, you

can use the USB connectors on the monitor.

9 USB downstream port Connect your USB device. You can only use this

connector after you have connected the USB cable to

the computer and USB upstream connector on the

monitor.

10 Stand lock feature To lock the stand to the monitor using a M3 x 6 mm

screw (screw not included).
