Dell UltraSharp U3415W User Manual

18 | About Your Monitor
Pin Assignments
DisplayPort Connector
Pin
Number
20-pin Side of the
Con
nected Signal Cable
1 ML0(p)
2 GND
3 ML0(n)
4 ML1(p)
5 GND
6 ML1(n)
7 ML2(p)
8 GND
9 ML2(n)
10 ML3(p)
11 GND
12 ML3(n)
13 GND
14 GND
15 AUX(p)
16 GND
17 AUX(n)
18 GND
19 Re-PWR
20 +3.3 V DP_PWR

Dell UltraSharp U3415W Specifications

General

Color	black
Screen Type	led
Tiltable	yes
Webcam	no
OS Compatibility	windows
Screen Size	34 inches
Panel Type	ips
Aspect Ratio	21:9
Resolution	3440 x 1440
Refresh Rate	60hz
Horizontal Viewing Angle	172 degrees
Vertical Viewing Angle	178 degrees
Response Time	8 milliseconds
Brightness	300 candela per square meter
Contrast Ratio	2, 000, 000:1
Synchronization	not applicable
HDR	no
Built-In Speakers	yes
HDMI Ports	1
Power Saving Mode	0.5 watts
Power Consumption	55 watts
Depth with Stand	8.5 inches
Width with Stand	32.47 inches
Net Weight without Stand	24.8 pounds
