Steps
1. Align the stand to the slot with the display-assembly base.
2. Slide the stand into place into the slot on the display-assembly base.
Next steps
1. Follow the procedure in After working inside your computer.
Back cover
Removing the back cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the stand.
About this task
NOTE: Before removing the base cover, ensure that there is no SD card installed in the SD card slot on your computer.
The following image(s) indicate the location of the back cover and provides a visual representation of the removal procedure.
Removal and installation procedures for High Performance processors
45
