Dell XPS 13 9315 User Manual

NOTE: Some tests are meant for specific devices and require user interaction. Ensure that you are present in front of the
computer when the diagnostic tests are performed.
For more information, see SupportAssist Pre-Boot System Performance Check.
Built-in self-test (BIST)
System board built-in self-test (M-BIST)
About this task
Steps
1. Press and hold both the M key and the power button to initiate M-BIST.
2. The battery-status light illuminates in amber when there is a failure with the system board.
3. Replace the system board to fix the issue.
NOTE:
The battery status LED will not illuminate if there is no failure present with the system board. If further
troubleshooting is required, proceed with the applicable Guided Resolution for No Power/No POST, etc.
Display panel power rail built-in self-test (L-BIST)
About this task
Next steps
L-BIST (LCD Power Rail Test) is an enhancement to the single LED error code diagnostics and is automatically initiated
during POST. L-BIST isolates if the LCD is receiving power from the system board. L-BIST checks if the system board is
supplying power to the LCD by performing an LCD Power Rail test. If there is no power going to the LCD, the battery status
LED flashes a [2,8] LED error code.
62
Troubleshooting

Dell XPS 13 9315 Specifications

General

HD type	3K
Panel type	WVA
Pixel density	267 ppi
Display diagonal	13 \
Display brightness	500 cd/m²
Display resolution	2880 x 1920 pixels
Native aspect ratio	3:2
Anti-reflective coating	Yes
Internal memory	16 GB
Memory clock speed	2133 MHz
Internal memory type	LPDDR4x-SDRAM
Ethernet LAN	No
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Wi-Fi data rate (max)	2400 Mbit/s
WLAN controller manufacturer	Intel
AC adapter power	45 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	2.25 A
AC adapter output voltage	20 V
Battery voltage	11.4 V
Battery capacity	- mAh
Battery recharge time	3 h
Number of battery cells	3
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Rear camera type	Single camera
Video capturing speed	30 fps
Rear camera resolution	3840 x 2160 pixels
Rear camera resolution (numeric)	10 MP
Front camera resolution (numeric)	5 MP
Position location	-
Audio system	Waves MaxxAudio
Speaker power	2 W
Device type	Tablet PC
Form factor	Slate
Product color	Blue
Cables included	AC
Pixel pitch	0.095 x 0.095 mm
Display response rise/fall	35 ms
Processor cache	12 MB
Processor cores	10
Processor family	Intel® Core™ i7
Processor frequency	- GHz
Processor boost frequency	4.7 GHz
SSD interface	M.2, PCI Express
Storage media	SSD
Internal storage capacity	512 GB
Platform	Windows
Trial software	McAFee Livesafe 12 months, No Microsoft Office Included
Operating system language	ENG, ESP, FRE
Operating system installed	Windows 11 Home
Operating system architecture	64-bit
Graphics card	Iris Xe Graphics

Weight and Dimensions

Depth	201.2 mm
Width	292.5 mm
Height	7.4 mm
Weight	740 g
