38
DOOR ASSEMBLY
■ Grip the door (as indicated in fig-
ure 42) and refit it in reverse
order of removal procedure.
DISMANTLING THE DOOR
Please operate as follows:
■ Open the door completely.
■ The swivel retainers of the rh
and lh hinges (fig. 42a) are
hooked onto the metal bar
above them (fig. 42b).
■ Lift the oven door slightly. The
notch on the bottom of the
hinge will disengage (fig. 42c).
■ Now pull the oven door for-
wards off the appliance. Release
both hinge sections from the
slots (fig. 42d).
Figure 42
Figure 42d
Figure 42c
Figure 42b
Figure 42a
