Chapter 1 Unpacking Check and Model Explanation|ASDA-A&A+ Series
Revision April 2009 1-7
1.3 Servo Drive and Servo Motor Combinations
The table below shows the possible combination of Delta ASDA-A and ASDA-A+ series servo drives and
ASMT and ECMA series servo motors. The boxes (îš…) in the model names are for optional configurations.
(Please refer to Section 1.2 for model explanation)
ASDA-A Series Servo Drive
Servo drive Servo motor
100W ASD-A0121Lîš… ASMT01L250îš…îš…
200W ASD-A0221Lîš… ASMT02L250îš…îš…
400W ASD-A0421Lîš…
ASMT04L250îš…îš…
750W ASD-A0721Lîš… ASMT07L250îš…îš…
1000W ASD-A1021Lîš…
ASMT10L250îš…îš…
2000W ASD-A2023Lîš… ASMT20L250îš…îš…
Low
inertia
3000W ASD-A3023Lîš…
ASMT30L250îš…îš…
1000W ASD-A1021Mîš… ASMT10M250îš…îš…
1500W ASD-A1521Mîš…
ASMT15M250îš…îš…
2000W ASD-A2023Mîš… ASMT20M250îš…îš…
Medium
inertia
3000W ASD-A3023Mîš…
ASMT30M250îš…îš…
