Delta AS228R-A User Manual

4.9.3 Wiring AS08AD-C
I2+
I2-
250
0V
24V
24 VDC
DC/DC
Con vert er
+15V
-1 5V
AG
*3
-2 0m A~+2 0m A
I1+
I1-
1M
AG
1M
* 2
FE
+
-
+
-
+24V
0V
4m A~+20 m A
-20 mA ~+20 mA
+24 V
+
-
I3+
I3-
* 2
FE
* 2
FE
+24 V
0V
0V
CHX
* 4
CHX
* 4
CHX
*4
250
25 0
1M
AG
1M
25 0
25 0
1M
A G
1M
25 0
Shielded c able *1
Shielded c able *1
Shielded c able *1
4-wire: cur rent in put
2-wire: curren t inp ut
3-wire: cu rrent inp ut
*1. Use shielded cables to isolate the analog input signal cable from other power cables.
*2. Connect FE of the shielded cable to ground.
*3. Connect the terminal to ground.
*4. Every channel can work with the wiring shown above.
