Delta AS228R-A User Manual

Error
Code
(16#)
Description Solution Flag Log
module is normal.
1608
The Internal factory calibration or
the CJC is abnormal.
If the problem persists, contact the local authorized
distributors.
SM10 V
1609
-
160F
Reserved (Error codes for the extension modules)
200A Invalid instruction
Check the syntax error step in the program. Modify and
compile the program and then download the program
again.
SM5 V
6010
The number of MODBUS TCP
connections exceeds the range.
Check the number of superior devices (maximum is 32).
SM
1092
V
6011
The number of EtherNet/IP
connections exceeds the range.
Check the number of connections (maximum is 16).
SM
1093
V
C000
-
CFFF
The program syntax is incorrect.
Save the PLC program and hand the file to the company
or the technicians.
12.2.3 ERROR LED Indicators Blinking Rapidly Every 0.2 Seconds
The blinking happens when the power supply 24 VDC of the CPU module is disconnected, or the power supply is not
sufficient, not stable or abnormal.
Error
Code
(16#)
Description Solution Flag Log
002A The external voltage is abnormal.
Check whether the external 24 V power supply to the
module is normal.
SM7 V
12.2.4 ERROR LED Indicators Slow Blinking Every 3 Seconds and
Lighting up for 1 Second
Error
Code
(16#)
Description Solution Flag Log
0040
The converted value in the
function card 1 (AS-F2AD) or in
the built-in AD input channel 1
exceeds the setting range.
Check the actual input signal SM27 H
0041
The converted value in the
function card 1 (AS-F2AD) or in
the built-in AD input channel 2
exceeds the setting range.
Check the actual input signal
SM27 H
0042
The converted value in the input
channel 1 of the function card 2
(AS-F2AD) exceeds the setting
range.
Check the actual input signal
SM27 H
0043
The converted value in the input
channel 2 of the function card 2
(AS-F2AD) exceeds the setting
range.
Check the actual input signal
SM27 H
