Delta AS300N-A User Manual

Chapter 2 Specifications and System Configuration
2-8
2_
Model
Item
AS228R-A
AS218RX-A
AS228T-A
AS218TX-A
AS228P-A
AS218PX-A
Bulb
20W (24VDC)
100W (230VAC)
N/A N/A
Maximum
output
frequency
Resistance
1Hz 200kHz 200kHz
Inductance
0.5Hz N/A N/A
Bulb
1Hz N/A N/A
Maximum
Response
time
OFF→ON
10 μs
2.5 μs
2.5 μs
ON→OFF
Analog outputs
AS218 Series: 2 outputs
Analog output resolution
AS218 Series: 12bits
Analog output mode
AS218 Series: -10V~10V (voltage mode) or 0mA~20mA (currentmode)
*1: Life cycle curve
Contact Current(A)
20
0.5
0.1
0.2
30
50
0.3 0.7
1 2
200
300
500
100
1000
2000
3000
Operation(X10 )
3
120VAC Resistive
30VDC Inductive(t=7ms)
240VAC Inductive(cos 0.4)
ψ=
120VAC Inductive(cos =0.4)ψ
30VDC
Inductive
(t=40ms)
2.2.3 CPU Module Profiles
 AS324MT-A/AS332T-A/AS332P-A/AS300N-A
8
75
92
98.3
88
80
1
2
COM1
COM2
5
0
OUT
4
1
2
3
8
9
11
10
2
102
7
5
6
4
IN
3 11
AS324MT
0
1
8
9
40
1
BAT. LO W
ERROR
RUN
POWER
Ethernet
6
7
3
10
11
12
7
4
5
6
9
13
Unit: mm
