3.1.4 Specification of ECMA Motor U, V, W Power Cable
Motor Model
U, V, W／Connector of Brake
Terminal
Definition
ECMA-C1040FS (50 W)
ECMA-C△0401S (100 W)
ECMA-C△0602S (200 W)
ECMA-C△0604S (400 W)
ECMA-C△08047 (400 W)
ECMA-C△0807S (750 W)
ECMA-C△0907S (750 W)
ECMA-C△0910S (1000 W)
A
ECMA-C1040FS (50 W)
ECMA-C△0401S (100 W)
ECMA-C△0602S (200 W)
ECMA-C△0604S (400 W)
ECMA-C△08047 (400 W)
ECMA-C△0807S (750 W)
ECMA-C△0907S (750 W)
ECMA-C△0910S (1000 W)
*：with brake
B
ECMA-G△1303S (300 W)
ECMA-E△1305S (500 W)
ECMA-F11305S (500 W)
ECMA-G△1306S (600 W)
ECMA-F△1308S (850 W)
ECMA-G△1309S (900 W)
ECMA-C△1010S (1000 W)
ECMA-E△1310S (1000 W)
ECMA-F11313S (1300 W)
ECMA-E△1315S (1500 W)
ECMA-F11318S (1800 W)
ECMA-C△1020S (2000 W)
ECMA-E△1320S (2000 W)
ECMA-C△13304 (3000 W)
C
