Delta Compact Drive MS300 IP66/NEMA 4X Series User Manual

Chapter 8 Optional Cards  MS300 (IP66 / NEMA 4X)
8-11
Environment
Noise immunity
ESD (IEC 61800-5-1, IEC 6100-4-2)
EFT (IEC 61800-5-1, IEC 6100-4-4)
Surge Test (IEC 61800-5-1, IEC 6100-4-5)
Conducted Susceptibility Test (IEC 61800-5-1, IEC 6100-4-6)
Operation / Storage
Operation: -10–50 ºC (temperature), 90 % (humidity)
Storage: -25–70 ºC (temperature), 95 % (humidity)
Shock / Vibration resistance
International standards:
IEC61131-2, IEC68-2-6 (TEST Fc) / IEC61131-2 & IEC 68-2-27 (TEST Ea)
 Installation
PROFIBUS DP connector pin assignment
PIN PIN name Definition
1
6
5
9
1 -
Not defined
2 -
Not defined
3 Rxd / Txd-P
Sending / receiving data P(B)
4 -
Not defined
5 DGND
Data reference ground
6 VP
Power voltage – positive
7 -
Not defined
8 Rxd / Txd-N
Sending / receiving data N(A)
9 -
Not defined
 LED Indicator & Troubleshooting
There are two LED indicators on
the CMM-PD01: POWER LED and NET LED. POWER LED displays the
status of the working power. NET LED displays the connection status of the communication.
POWER LED
LED status Indication Corrective Action
Green light on Power supply in normal status. No action is required.
Off No power
Check if the connection between the CMM-PD01
and the AC motor drive is normal.
NET LED
LED status Indication Corrective Action
Green light on Normal status No action is required.
Red light on
The CMM-PD01 is not connected to
PROFIBUS DP bus.
Connect the CMM-PD01 to the PROFIBUS DP bus.
Red light
flashes
Invalid PROFIBUS communication
address
Set the PROFIBUS address of the CMM-PD01
between 1–125 (decimal).
Orange light
flashes
The CMM-PD01 fails to
communicate with AC motor drive.
Switch off the power and check whether the
CMM-PD01 is installed correctly and connected
normally to the AC motor drive.
