Ethernet Communication Module DVPEN01-SL
DVP-PLC Operation Manual
14
5 Setting up Software
This section gives instructions on how to set up DVPEN01-SL by DCISoft and explanations on each setup
page. Before you start a setup page, you have to select “Ethernet” in the communication setting. Next, you can
search by IP address or use Auto-Search. You also can open the setup page for DVPEN01-SL by RS-232.
DVPEN01-SL is set up by UDP port 20006; therefore, you have to be aware of the relevant settings of the
firewall.
5.1 Setting up Communication & Searching for Modules
Communication settings
1. Open DCISoft in your PC and click on “Communication Setting”.
2. Select “Ethernet” as the transmission type.
