Delta ME300 Series User Manual

Chapter 5 Main Circuit TerminalsME300
5-6
Frame A
Figure 5-8
 If you install at Ta 50°C above environment, use copper wires that have a
voltage rating of 600V
and are temperature resistant to 90°C or above.
 If you install at Ta 50°C environment, use copper wires that have a voltage rating of 600V and
are
temperature resistant to 75°C or 90°C.
 For VFD2A5ME11ANNAA, VFD2A5ME11ANSAA:
If you install at Ta 40
°C above environment, use copper wires that have a voltage rating of 600V
and are temperature resistant to 90°C or above.
 To be UL installation compliant, you must use copper wires when installing.
The wire gauge is based
on a temperature resistance of 75°C, in accordance with UL requirements and recommendations.
Do not reduce the wire gauge when using high-temperature resistant wires.
Models
Main Circuit Terminals
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3,
DC-, DC+/+1, +2/B1, B2
Terminals
Max. Wire
Gauge
Min. Wire
Gauge
Screw & Torque
(±10%)
Max. Wire
Gauge
Min. Wire
Gauge
Screw & Torque
(±10%)
VFD0A8ME11ANNAA
VFD0A8ME11ANSAA
2.5mm
2
[14AWG]
0.75 mm
2
[18 AWG]
M3.5
9 kg-
cm
[7.8 lb-
in.]
[0.88 Nm]
2.5 mm
2
[14 AWG]
2.5 mm
2
[14 AWG]
M3.5
9 kg-
cm
[7.8 lb-
in.]
[0.88 Nm]
VFD1A6ME11ANNAA
VFD1A6ME11ANSAA
2.5 mm
2
[14 AWG]
VFD2A5ME11ANNAA
VFD2A5ME11ANSAA
VFD0A8ME21ANNAA
VFD0A8ME21ANSAA
0.75 mm
2
[18 AWG]
VFD1A6ME21ANNAA
VFD1A6ME21ANSAA
1.5 mm
2
[16 AWG]
VFD2A8ME21ANNAA
VFD2A8ME21ANSAA
2.5 mm
2
[14 AWG]
VFD0A8ME23ANNAA
VFD0A8ME23ANSAA
0.75 mm
2
[18 AWG]
VFD1A6ME23ANNAA
VFD1A6ME23ANSAA
VFD2A8ME23ANNAA
VFD2A8ME23ANSAA
VFD4A8ME23ANNAA
VFD4A8ME23ANSAA
1.5 mm
2
[16 AWG]
VFD1A5ME43ANNAA
VFD1A5ME43ANSAA
0.75 mm
2
[18 AWG]
VFD2A7ME43ANNAA
VFD2A7ME43ANSAA
Table 5-3
