10
!
!
4. Installation
4.1 Installation Location
WARNING！
！！
！ Death and serious injuries may occur.
●
Do not install the unit near/on the flammable objects.
●
Please mount the unit tightly on the solid/smooth wall.
●
In order to ensure the safety of installers, installer shall be at
least two people to process the installation.
●
When moving the Inverter, installer shall not stand under
machines.
CAUTION！
！！
！ Machine and equipment damage may occur
●
Do not install the unit at the location that directly expose to
sunlight.
4.2 Mounting
This unit is a wall-mounting system. Please ensure the installation is
perpendicular and with AC plug at the bottom. Do not install the device on a
slanting wall. The dimensions of mounting bracket are shown as figure below.
There are 7 pcs(RPI-H3)/12pcs(RPI-H5) of M5 screws required for mounting
plate. Fix the supplied wall-mount plate securely on the wall before mounting
the inverter to the mounting plate.
To Next Page
