7.2.4 Operation Data
Has 4 pages, record the maximum and/or minimum values of history, including
voltage, current, power and temperature.
Operation Data – 1/4
21. Jun 2010 13:50
Input1
Voltage
Current
Power
Voltage
Current
Power
Input2
Maximum
(Vdc)
(A)
(W)
(Vdc)
(A)
(W)
811
25.2
11200
785
26.3
10301
Operation Data – 2/4
21. Jun 2010 13:50
L1
Voltage
Current
Power
Voltage
Current
Power
Voltage
Current
Power
L2
L3
Maximum
(Vdc)
(A)
(W)
(Vdc)
(A)
(W)
(Vdc)
(A)
(W)
247
30.5
6810
244
30.3
6756
245
30.1
6745
Operation Data – 4/4
21. Jun 2010 13:50
Temperature Max. Min.
Inside
Heatsink - 1
Heatsink - 2
Heatsink - 3
(℃)
(℃)
(℃)
(℃)
59.3
75.5
74.2
73.6
15.7
15.3
15.2
15.2
Operation Data – 3/4
21. Jun 2010 13:50
Output
Voltage
Current
Power
Frequency
(Vdc)
(A)
(W)
(Hz)
Maximum
247
30.5
20311
50.10
ENT
or
ENT
or
ENT
or
ENT
or
Figure 7-9 Operation data flow chart
7.2.5 Inverter Information
This page has the following information: serial number, firmware version,
installation date and inverter ID. If user wants to change inverter ID, please refer
to 7.2.6.3 Install Setting.
.
Inverter Information
21. Jun 2010 13:50
Serial Number
DSP-Version
Installation Date
AE46000006
05.Jan.2009
1.80
Red.-Version 1.17
Comm.-Version
1.99
Inverter ID 001
Country Custom
Figure 7-10 Inverter information page
