Chapter 1 Introduction
_
VFD-B Series
1-4
Revision 10/2005, BE13, SW V4.08
40-100HP/30-75kW (Frame E, E1)
75-100HP/55-75kW (Frame F)
1.3 Prep
aration for Inst
allation and Wiring
1.3.1 Remove Keypad
1-3HP/0.75-2.2kW (Frame A, A1, A2)
3-5HP/2.2-3.7kW (Frame B)
11
13
