Revision 10/2005, BE13, SW V4.08 A-1
Appendix A Specifications
Voltage Class 230V Class
Model Number VFD-XXXB 007 015 022 037 055 075 110 150 185 220 300 370
Max. Applicable Motor Output
(kW)
0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37
Max. Applicable Motor Output (hp) 1.0 2.0 3.0 5.0 7.5 10 15 20 25 30 40 50
Rated Output Capacity (kVA) 1.9 2.5 4.2 6.5 9.5 12.5 18.3 24.7 28.6 34.3 45.7 55.0
Rated Output Current (A) 5.0 7.0 11 17 25 33 49 65 75 90 120 145
Maximum Output Voltage (V) 3-Phase Proportional to Input Voltage
Output Frequency (Hz) 0.1~400 Hz
Output Rating
Carrier Frequency (kHz) 1-15 1-9
Single/3-phase 3-phase
Rated Input Current (A)
11.9/
5.7
15.3/
7.6
22/
15.5
20.6 26 34 50 60 75 90 110 142
Input Current for 1-phase
models when using 3-phase
power
7.0 9.4 14.0 --
Rated Voltage/Frequency
Single/3-phase
200-240 V, 50/60Hz
3-phase
200-240V, 50/60Hz
Voltage Tolerance +-10%(180~264 V)
Input Rating
Frequency Tolerance +-5%(47~63 Hz)
Cooling Method
Natural
Fan Cooled
Weight (kg) 2.7 3.2 4.5 6.8 8 10 13 13 13 13 36 36
Voltage Class 460V Class
Model Number VFD-XXXB 007 015 022 037 055 075 110 150 185 220 300 370 450 550 750
Max. Applicable Motor Output
(kW)
0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Max. Applicable Motor Output (hp) 1.0 2.0 3.0 5.0 7.5 10 15 20 25 30 40 50 60 75 100
Rated Output Capacity (kVA) 2.3 3.2 4.2 6.5 9.9 13.7 18.3 24.4 28.9 34.3 45.7 55.6 69.3 84 114
Rated Output Current (A) 2.7 4.2 5.5 8.5 13 18 24 32 38 45 60 73 91 110 150
Maximum Output Voltage (V) 3-phase Proportional to Input Voltage
Output Frequency (Hz) 0.1~400 Hz
Output Rating
Carrier Frequency (kHz) 1-15 1-9 1-6
3-phase
Rated Input Current (A)
3.2 4.3 5.9 11.2 14 19 25 32 39 49 60 63 90 130 160
Rated Voltage 3-phase 380 to 480 V
Voltage Tolerance +-10%(342~528 V)
Input Rating
Frequency Tolerance +-5%(47~63 Hz)
Cooling Method
Natural Fan Cooled
Weight (kg) 2.7 3.2 4.5 6.8 8 10 13 13 13 13 36 36 36 50 50
