8-4 Operation, Storage and Transportation Environments
DO NOT expose the AC motor drive to a poor environment, such as one with dust, direct sunlight, corrosive or
inflammable gases, humidity, liquids or excessive vibration. The salt in the air must be less than 0.01 mg/cm
2
Environment
Installation
IEC60364-1/IEC60664-1 pollution degree 2. Indoor use only.
Surrounding
Temperature
Operation
Between -10–40°C, up to 50°C with derating for the operation
Between
40–50°C
with
Derating
2.2–4 kW: for every 1°C increase in temperature,
decrease the drive’s rated current by 2.2%
5.5–30 kW: for every 1°C increase in temperature,
decrease the drive’s rated current by 2.5%
37–75 kW: for every 1°C increase in temperature,
decrease the drive’s rated current by 2.0%
Transportation
-20–60
o
C
Non-condensing, non-freezing.
Rated
Humidity
Storage/
Transportation
Max. 90%
Altitude
Operation
If the AC motor drive is installed at an altitude of 0–1000 m, follow
normal operation restrictions. For altitudes of 1000–3000 m,
decrease the drive’s rated current by 1% or lower the temperature
by 0.5°C for every 100 m increase in altitude. The maximum
altitude for corner grounding is 3000 m. If installing at an altitude
higher than 3000 m is required, contact Delta for more information.
Power
TN system
*1*2
Package
Drop
ISTA procedure 1A (according to weight) IEC60068-2-31
Transportation
Vibration
1.0 mm, peak to peak value range from 2–13.2 Hz;
0.7–1.0 G range from 13.2–55 Hz;
1.0 G range from 55–512 Hz.
Compliance with IEC 60068-2-27.
Compliance with IEC/EN 60068-2-27
Protection
NEMA 1/IP20
EMC Level IEC 61800-3 and IEC 61000-4
NOTE:
*
1
: TN system: The neutral point of the power system connects directly to the ground. The exposed
metal components connect to the ground through the protective grounding conductor.
2
: Single-phase models use a single-phase three-wire power system.
Table 8-4
