6-6 EMC Filter
The table below shows external EMC filter models for each ED-S series motor drive. Choose
corresponding zero phase reactors and applicable shielding cables according to the required noise
emission and electromagnetic interference rating for the best configuration and anti-interference
performance. If radiation emission (RE) is not a concern on site and you only need conducted emission
(CE) to reach EN55011 Class A, you do not need to install a zero phase reactor on the input side to
reach the EMC standard.
220V Models
VFD-ED
EMC Filter
Model #
Zero Phase Reactor
Carrier
Frequency
EN12015
Frame
Motor Drive
Model #
Rated Input
Current (A)
Input Side (R/S/T)
Conducted Emission
Radiation
Emission
Length of Output
Shielded Cable 50 m
B
VFD022ED21S 24
B84142A0042R122
RF008X00A or
T60006L2040W453
Carrier
frequency by
default
CLASS A CLASS A
VFD037ED21S 34
B84142A0042R122
RF008X00A or
T60006L2040W453
CLASSA CLASSA
VFD040ED23S 20 EMF035A23A
RF008X00A or
T60006L2040W453
CLASS A CLASS A
C
VFD055ED23S 23 EMF056A23A
RF004X00A or
T60006L2050W565
CLASS A CLASS A
VFD075ED23S 30 EMF056A23A
RF004X00A or
T60006L2050W565
CLASS A CLASS A
VFD110ED23S 47 EMF056A23A
RF004X00A or
T60006L2050W565
CLASS A CLASS A
D
VFD150ED23S 56
B84143D0150R127
RF002X00A or
T60006L2160V066
CLASS A CLASS A
VFD185ED23S 73 B84143D0150R127
RF002X00A or
T60006L2160V066
CLASS A CLASS A
VFD220ED23S 90 B84143D0150R127
RF002X00A or
T60006L2160V066
CLASS A CLASS A
E
VFD300ED23S 132
B84143D0150R127
RF002X00A or
T60006L2160V066
CLASS A CLASS A
VFD370ED23S 161 B84143D0200R127
RF300X00A or
T60006L2160V066
CLASS A CLASS A
Table 6-38
460V Models
VFD-ED
EMC Filter
Model #
Zero Phase Reactor
Carrier
Frequency
EN12015
Frame
Motor Drive
Model #
Rated Input
Current (A)
Input Side (R/S/T)
Conducted Emission
Radiation
Emission
Length of Output
Shielded Cable 50 m
B VFD040ED43S 11.5 EMF018A43A
RF008X00A or
T60006L2040W453
Carrier
frequency by
default
CLASS A CLASS A
C
VFD055ED43S 14 EMF018A43A
RF004X00A or
T60006L2050W565
CLASSA CLASS A
VFD075ED43S 17 EMF018A43A
RF004X00A or
T60006L2050W565
CLASS A CLASS A
VFD110ED43S 24 EMF033A43A
RF004X00A or
T60006L2050W565
CLASS A CLASS A
VFD150ED43S 30 EMF033A43A
RF004X00A or
T60006L2050W565
CLASS A CLASS A
VFD185ED43S 37 B84143D0075R127
RF004X00A or
T60006L2050W565
CLASS A CLASS A
D
VFD220ED43S 47
B84143D0090R127
RF002X00A or
T60006L2160V066
CLASS A CLASS A
VFD300ED43S 58 B84143D0090R127
RF002X00A or
T60006L2160V066
CLASS A CLASS A
E
VFD370ED43S 80
B84143D0200R127
RF300X00A or
T60006L2160V066
CLASS A CLASS A
VFD450ED43S 100 B84143D0200R127
RF300X00A or
T60006L2160V066
CLASS A CLASS A
VFD550ED43S 128 B84143D0200R127
RF300X00A or
T60006L2160V066
CLASS A CLASS A
VFD750ED43S 165 B84143D0200R127
RF300X00A or
T60006L2160V066
CLASS A CLASS A
Table 6-39
